ARTS 2610: Designing Musical Games

Arts Department, Rensselaer Polytechnic Institute

Monday/Thursday, 12:00-1:50pm, VAST Lab, SAGE 2411

Instructor: Rob Hamilton, West Hall 305/6

e: hamilr4 [at] rpi [dot] edu

w: https://robertkhamilton.github.io/

Office Hours: TBD

COURSE SYLLABUS - Fall, 2024

PREREQUISITE

None

COURSE DESCRIPTION

One of the most exciting areas of music technology development is happening in the realm of gaming and interactive virtual space. Music and Sound Design play crucial roles in the design of gaming environments, narratives and flow. And as designers create ever more innovative game experiences featuring rich graphics, fast multiplayer networking and next-generation controllers, new techniques for creating immersive music and sound for games to complement and showcase these advances are not only possible but necessary.

This Studio class will explore cutting edge techniques for building interactive sound and music systems for games and 2D/3D rendered environments. To better understand the link between virtual space and sound, students will learn the basics of designing sound and composing music for interactive game spaces by designing and implementing rich musical games within the Unity and Unreal gaming engines. Coursework will require the ability and desire to code game logic and design game environments. Techniques for integrating sound and music within games including game-centric middleware tools like FMOD and WWISE, interactive sound synthesis and computer networking using Open Sound Control may be explored.

Working in teams or on their own, students will design their own music-rich game experience, compose music, design sound material, and implement their own playable interactive musical game experiences.

CATALOG DESCRIPTION

Students will explore the artistic role of music and sound in gaming by building their own interactive sound and music-rich games and 2D/3D rendered environments. Within the context of their own creative game projects, students will learn the basics of designing sound and composing music for interactive game spaces. Using workflow programming languages and software tools, students will program basic gaming interactions, link them to interactive audio software, and create a musical gaming experience.

LEARNING OUTCOMES

    Students who successfully complete this course will demonstrate...
  1. an understanding and appreciation of game design and musical creation through an awareness of the many disciplines underlying the field including: software design and programming, interaction design, listening skills, musical theory, musical acoustics, digital audio theory, and digital signal processing.
  2. basic technical facility in the areas of game development, audio recording, editing, sound synthesis, software development and post production.
  3. creativity and resourcefulness through the creation of musical game environments and composition of your own sonic projects

EVALUATION

Evaluation is based on the following:

CLASS PARTICIPATION

You will be required to present some of your assignments to the class, to show your work within the software environment you used to create it, and to engage the class in discussion of your work. When you are not presenting your own work, you need to be attentive to whoever is presenting, and to engage them in discussion of their work. Failure to participate in class will lower your grade.

ATTENDANCE

You must attend class to succeed in this course.

  1. Since much of the class is focused on listening to and discussing work in class, attendance is mandatory.
  2. ** More then two unexcused absences will affect your grade, detracting 1/2 grade each additional 2 unexcused absences. **
  3. Late arrivals are very disruptive - continued late arrival will affect your grade.
  4. It should go without saying but no use of mobile devices or personal computers during class time (except for as required by the coursework itself) is acceptable. Continued violations will be treated as an unexcused absence.

STATEMENT REGARDING ACADEMIC INTEGRITY

Collaboration between students in this course is strongly encouraged. Likewise, students are encouraged—indeed, to some extent required—to exchange ideas, opinions and information . You are also encouraged to help each other in the lab and with performance, production, and presentation of composition projects.

Plagiarism of any kind is in direct violation of University policy on Academic Dishonesty as defined in the Rensselaer Handbook, and penalties for plagiarism can be severe. In this class you will be expected to attribute due credit to the originator of any ideas, words, sounds, or music which you incorporate substantially into your own work. This applies particularly to citation of sources for sonic "samples" included in your compositions.

The use of automated technical aids (e.g. ChatBots, AI code plugins) is not strictly forbidden but if used MUST be documented in great detail and discussed with the Professor prior to use in a graded project/assignment.

Submission of any assignment that is in violation of this policy may result in a grade of F for the assignment in question. Violation of this policy will be reported, as defined in the Rensselaer Handbook

DISABILITY SERVICES FOR STUDENTS

Students requiring assistance are encouraged to contact Disability Services: http://doso.rpi.edu/dss to discuss any special accommodations or needs for this course.

OFFICE HOURS

Office Hours for Fall, 2024 will be TBD

TEXTBOOKS / REPOSITORIES / FOUNDATIONAL MATERIAL

Designing Sound, by Andy Farnell (book missing)

Musimathics (Vol. I), by Gareth Loy

Musimathics (Vol, II), by Gareth Loy

Theory and Techniques of Electronic Music, by Miller Puckette




FILE UPLOAD LINK (BOX)




COURSE SCHEDULE

The proposed course topics and schedule will be as follows (take note of project due dates!). Based on class progress and interests, this schedule is subject to change. Special topics, guest lectures, supplemental reading, listening and additional assignments to be announced.

Week 1:
Week 2:
Tuesday, 9/3

Intro music:
      Idioteque (Radiohead cover) by Amanda Palmer
      Idioteque by Radiohead
      Mild und Leise by Paul Lansky (sample source)

Lecture: Designing Musical Games :: Gaming Musical Design
The role of sound and music in games; filmic influences; spectra of interactivity

- Destiny Trailer: https://www.youtube.com/watch?v=VFh5ArG46_M
- "Hope for the Future" https://www.youtube.com/watch?v=163_C5UVU-I
- Destiny 2 musical lore: https://gamerant.com/destiny-2-paul-mccartney-hope-for-the-future-song-lore/
- Marty O'Donnell talks Destiny/McCartney: https://www.youtube.com/watch?v=xsmRNGrh7Vk

- Journey Trailer: https://www.youtube.com/watch?v=2FZkTXs3Td8
- Journey Grammy Nomination: Forbes
- Austin Wintory Interview (BAFTA): https://www.youtube.com/watch?v=WcuMLbKTgwc

- Portal: Still Alive by Jonathan Coulton

- Smule Magic Piano: https://apps.apple.com/us/app/magic-piano-by-smule/id421254504
- Smule Musical Scoring paper: Social Composition: Musical Data Systems for Expressive Mobile Music

- Zatoichi: The Blind Swordsman: https://www.imdb.com/title/tt0363226/

- Q3OSC (Quake 3) paper: Q3OSC: or How I Learned to Stop Worrying and Love the Game
- Nous Sommes Tous Fernando: https://ccrma.stanford.edu/~rob/portfolio/fernando/

Week 3:
Monday, 9/9

Frequency       Root       MIDI (0-127)       Pitch       Speed       Sharp(#)       Octave       Flat(b)       Timbre       Partial       Equal Temperament       C4, D, E, F, G...       Loudness       Amplitude       Harmonic       Volume       Fifth       Chromatic       Gain       Fourth       Diatonic       Note       Third       Consonance       Scale       Major       Dissonance       Interval       Minor       Cent       Mode       Perfect       Microtone       Chord       Sample       Period       Sample       44.1 kHz       Compact Disc       Sampling Rate       48 kHz       96 kHz       Bit Depth       Nyquist Theorem       Quantization       Aliasing/Foldback       Resolution       Distortion       Signal       Clipping       Noise       PCM


Intro music: Mortal Kombat!!!!!!!

The Art and Science of Foley
aka: MOR-TAAL--KOMMMM-BAAAAT-day

Video : Digital Foley: "Mortal Kombat Foley: The Sound of Violence"
Video: "The Hunger Games" & "Frozen" Foley Artists Turn the Sound of Junk into Miracles

Week 4:
Monday, 9/16

Intro Music: Journey Playthough (Spoiler Warning)

Playing Audio in Unity: Overview
        - AudioSource.PlayOneShot: Plays an AudioClip, and scales the AudioSource volume by volumeScale.
        - Play: Plays the clip.
        - PlayDelayed: Plays the clip with a delay specified in seconds. Users are advised to use this function instead of the old Play(delay) function that took a delay specified in samples relative to a reference rate of 44.1 kHz as an argument.
        - PlayOnGamepad: Enable playing of audio source though a specfic gamepad.
        - PlayScheduled: Plays the clip at a specific time on the absolute time-line that AudioSettings.dspTime reads from.
Week 5:
Monday, 9/23

NO CLASS

READING:
        - Chunity Paper
        - MIDI.CITI: Designing an Experience-oriented Musical Cityscape

Links:
        - Chunity on Unity Asset Store
        - Chunreal Git repository

Week 6:
Monday, 9/30

Intro Music:
        - U2 With or Without You @ The Sphere, Las Vegas (2023)
        - Brian Eno Music for Airports (1978)

Bloom by Brian Eno (app, 2008)
Polyfauna by Radiohead (app, 2014)
Biophilia by Bjork (app, 2011)

Spore: Will Wright and Brian Eno (2008)
GDC 2008: Kent Jolly on Procedural Music systems in Spore
Usage of PD in Spore and Darkspore (paper, 2011)
Spore audio team interview

Proteus by David Kanaga (2013)
Generative Music Systems: Leonard Paul's music from "Sim-Cell": youtube
Martin Brinkmann patches: http://www.martin-brinkmann.de/pd-patches.html
RJDJ Abstractions: https://github.com/rjdj/rjlib

GG Music (Soundcraft/Starcraft II)
Paper: Soundcraft: Transducing StarCraft 2 (2013)
ChucK: https://chuck.cs.princeton.edu/

Week 7:
Monday, 10/7

Intro Music: The Hand That Feeds (cover - chamber ensemble version)

Unity Third Person audio project: RPI Box download (1.1 GB)
- Snapshot Transition types: Linear, Smoothstep, Squared, SquareRoot, BrickwallStart, BrickwallEnd
- AudioMixer Snapshot Weighted transitions: AudioMixer.TransitionToSnapshots
(same Snapshot video above)

Unity Audio Tutorials:
Audio Random Container: tutorial (Project Download (1 GB)
Audio Timelines: Working with Audio Tracks in Timeline

Perpetual Alpha (?): Unity 23.2 alpha: Audio Random Container
Download other Unity Versions...

Timeline Signals: Asset, Emitter, Receiver Overview video

Assignment #2: Sample-based game audio scene (- DUE DATE, FRIDAY, OCTOBER 18, 11:59:59 pm EST )

Using your favorite samples, either from our in-class recording challenge or new samples you make yourself, modify a Roll-A-Ball project OR the First or Third-Person Starter Assets scenes OR some other cool scene that has no sound, with sound and MAKE IT YOUR OWN. You can modify and add functionality or assets to the scene as needed/desired to make the game do what you'd like it to.
This assignment is looking to see you flex both your tech/implementation chops (following the examples we've played with in class) and your creative chops, with special focus on how you make your project personal and engaging through the use of sound and music.

The success of your scene will revolve around whether or not your scene is sonically-coherent, i.e. all the sounds exist and belong in the same space. Coherence can be helped by creative use of reverberation in game, by careful editing of sounds in Audacity, or simply through artistic choices you make in your role as sound-designer.
In addition to the project itself, create a detailed "call-sheet" list of all the sounds you will use/are using in the project, including variations. List file-names, extensions, durations, and any notes that would be helpful or useful to your programming team*. Please include a short paragraph or description of the overall-zeitgeist of your scene, and why we should care.
Please include examples of the following Unity audio processes in your scene:

    * Simple Audio Source playback (multiple)
    * Reverb Zones
    * Mixer Groups with exposed parameters and plugins/effects
    * C# scripting of audio playback events
    * 3D sound/distance-based attenuation
    * Varying pitch, amplitude, etc.
    * Sounds triggered through collision
    * An awesome looping stereo background "musical" track
    * Timeline audio tracks with signal-driven game events
    * Emergent gameplay that instigates some kind of interesting sound/music scape
    * EXTRA-CREDIT: Make your background track a multi-channel "stem"-based playback example
    * EXTRA-CREDIT: Use Chunity with ChucK audio scripts connected to your scene
    * EXTRA-CREDIT: include MIDI file control and/or Microphone input

Please upload your entire project to the Box dropbox folder using the same naming conventions as Assignment #1, i.e:
HOUSEKEEPING: box.rpi.edu file submission folder
- You all received an invitation to a shared "DMG Assignment Dropbox" Box folder. - zip up all your files into one .zip archive
- use the following naming convention: "a" + assignment # + "_" + rcs username + ".zip" (e.g. "a2_hamilr4.zip")
- if files are too crazy large, you can break your submission into multiple .zip archives. For example if you have 3 large .zip files, each would be titled as: "a2_hamilr4_1_of_3.zip", etc.


* the programming team is a lie...
Week 8:
Monday, 10/14
NO CLASS (Indigenous Peoples' Day)
Week 9:
Monday, 10/21
Intro Music: Walking on the Moon by The Police

Introduction to Unreal Engine 5

Blueprint Workflow Scripting Language, IDE basics, default projects, basic flow control

Audio in Unreal Engine 5.3
UE5: Legacy Audio system: Audio Listener, Audio Mixer, Sound Classes, and Sound Mixes
Sound Wave Assets: importing, properties
Audio Listener - Blueprint for moving from Camera to third-person character
Sound Attenuation (Volume): https://dev.epicgames.com/documentation/en-us/unreal-engine/sound-attenuation-in-unreal-engine#attenuation(volume)

Sound Cues: https://docs.unrealengine.com/5.3/en-US/sound-cues-in-unreal-engine/

http://blog.leapmotion.com/twist-gears-massive-vr-music-engine-carillon/
Carillon: https://www.youtube.com/watch?v=N6Me8B7Wst8
OSCCraft (Minecraft + Open Sound Control): https://github.com/robertkhamilton/osccraft

Footsteps via animation Blueprint (anim notify): https://docs.unrealengine.com/4.27/en-US/AnimatingObjects/SkeletalMeshAnimation/Sequences/Notifies/
Week 10:
Monday, 10/28

Footsteps continued

Dynamic footsteps via Ray Trace and Metasounds: tutorial video

MetaSounds Introduction
- Overview: Set of videos
- Epic tutorial: Quick Start: Bomb and Wind
- Epic tutorial: Procedural Music

Tutorial project download: .zip (big)

MetaSounds
- WavePlayer sample playback
- Random, Trigger Repeat, variables, parameter widgets
- Wave asset collections, Random Get, weights/probability
- Loop start, Loop duration


Set of introductory tutorials: Epic community tutorials
Week 11:
Monday, 11/4

Intro Music: Presque Rien n°1 by Luc Ferrari

Unreal Demo Game: Lyra @ fab.com
Exploring MetaSounds in Lyra | Inside Unreal

Introduction to Open Sound Control with Unreal
https://docs.unrealengine.com/5.0/en-US/osc-plugin-overview-for-unreal-engine/

Introduction to Sound Class and Sound Mix

ASSIGNMENT #3
TL;DR - For assignment 3 submit the following:
* Written Proposal emailed to me - due 11/8
* Unreal Project uploaded to Box - due 11/17
    ** Written Project description and Call Sheet
    ** Video Walkthrough

Assignment #3a Proposal Document (Due Friday, 11/8, 11:59:59 PM EST )
* Submit a written project proposal for your Assignment #3 Unreal Engine audio project (see below). This proposal should describe the scene you'll be creating, the types of sound assets and sound generation techniques you plan on using, and should show me that you've given thought to the overall direction and focus of your upcoming assignent.
* There is no "minimum" or "maximum" length to your design document submission; if you can succinctly explain your project in one sentence, all the better. However it is your responsibility to clearly explain your proposed project and the technologies you will leverage to create it to me.
* Email your proposal to me by the due date/time.

*NOTE* THIS DOCUMENT SHOULD HAVE YOUR NAME, THE DATE, THE NAME OF THIS CLASS AND THE TITLE OF YOUR PROJECT ON IT

Assignment #3b: Unreal audio scene (Due Sunday, 11/17, 11:59:59 PM EST )

This project represents your chance to showcase your understanding of the basic underlying principles of game sound and music within the Unreal Engine. Populate a simple Unreal scene using sound files downloaded from an online repository - or sound assets of your own creation (even better!). You can create an Unreal scene from scratch or use one of the many available Unreal project templates (displayed when you create a new Unreal project).

As always, the success of your scene will revolve around whether or not your scene feels coherent, i.e. all the sounds exist in the same space. Coherence can be helped by creative use of reverberation in game, by careful editing of sounds in Audacity, or simply through artistic choices you make in your role as sound-designer.

In addition to the project itself, create a detailed "call-sheet" list of all the sounds/assets/processes you will use/are using in the project, including variations. List file-names, extensions, durations, and any notes that would be helpful or useful to your programming team*. Please include a short paragraph or description of the overall-zeitgeist of your scene, and why we should care.

*NOTE* THIS DOCUMENT SHOULD HAVE YOUR NAME, THE DATE, THE NAME OF THIS CLASS AND THE TITLE OF YOUR PROJECT ON IT

Please include examples of the following Unreal audio processes in your scene:

    * Footsteps (for 1st and 3rd person scenes), or movement sounds (i.e. vehicle sounds) if you have a moving character
    * Simple Sound Assets
    * Randomized Sound Cues or Metasounds
    * Sound Assets/Cues/Metasounds with proximity volume attenuation
    * Sound Assets/Cues/Metasounds triggered by Box or Sphere trigger volumes
    * Sound Assets/Cues/Metasounds triggered by a keypress
    * Sound Cues/Metasounds with one or more parameters driven by in-game action or events
    * use of the Unreal Modular or Granular Synths
    * EXTRA-CREDIT:Audio SoundClass, Submixes and Audio Submix Effects
    * EXTRA-CREDIT: MIDI input, Open Sound Control output or input
*** I'm requesting you record a short simple play through video, YouTube style, showcasing all the elements in your project. Please include either a voice-over or text captions so that I know what's going on.
*** Name your project "a3_your-rcs-id.mov" or whatever extension/video type

Please upload your entire project to your Box folder in a zipped up sub-folder titled "Assignment #3".

Week 12:
Monday, 11/11

Open Sound Control in UE 5

Introduction to Wwise: Wwise 101 course

Overwatch WWise Tour 2016: Vol. 1/7 Audio in Overwatch, Vol. 5/7 Gameplay Information
Week 13:
Monday, 11/18

Wwise: 201 tutorial series (continued)...
Week 14:
Monday, 11/25

Optional In Class help day
Week 15:
Monday, 12/2
Final Project hacking-testing-feedback session
Week 16:
Monday, 12/9

FINAL DAY OF CLASS

Final Project hacking-testing-feedback session
FINAL PROJECT SUBMISSION

Tuesday, 12/17, 12:00 pm (NOON)

FINAL PROJECT OVERVIEW

Due: Tuesday, 12/17, 12:00 pm (NOON)

Your final project for Designing Musical Games will be, surprisingly, a musical-game, built using the tools and techniques we've investigated during this semester. That means your game can be built using game engines such as Unreal Engine or Unity, using the audio capabilities of the engines themselves or using an external audio environment such as Pure Data, ChucK or WWise. Sounds for your system should be your own, with music and samples edited in Audacity or your favorite DAW.

If you use stock music or sounds downloaded from the internet they should not make up the majority of your project; if you do download assets, please credit them in your project write-up.

For your final project, you will be expected to submit the following:
* A written overview of your project - this should be a well crafted overview document describing the technical and artistic choices you made in your project and how you made use of sound and interaction. Also any instructions on getting your system running need to be included here as well.
* A video play-test of your project - a short video capturing the game-play and all the interesting parts of your project you wish to showcase. A narrative overview or text captioning is required.
* Source code for your project - all files needed to run your project should be uploaded to the Box folder. If you can compile an executable of your system, that's great, though for some projects that will not be possible.

Your project may encompass any or all of the sound and music compositional/music/sonic techniques and technologies we have investigated during the course of this class including fixed media sound design and composition with Audacity or another DAW, workflow interactive programming systems with Pure Data, ChucK or some other audio programming environmnet, Unity, Unreal, Metasounds and/or WWise/FMod. Your proposal should address the integration (technical) and the mapping (artistic) of your data and control systems from game engine to audio layer, and vice versa.

REMINDER: Upload your project submission files to the shared "DMG Assignment Dropbox" Box folder.
- zip up all your files into one .zip archive
- use the following naming convention: "a" + assignment # + "_" + rcs username + ".zip" (e.g. "final_hamilr4.zip")
- if files are too crazy large, you can break your submission into multiple .zip archives. For example if you have 3 large .zip files, each would be titled as: "final_hamilr4_1_of_3.zip", etc.
